| ABOUT PCD (Poly Crystalline Diamond) |
| |
PCD can be used to machine a wide range of non-ferrous metals (aluminium and aluminium alloys, magnesium alloys, copper, brass, bronze, zinc, pre-sintered and sintered tungsten carbide) and non-metalic materials such as wood based materials (chipboard, fibreboard, particle board, laminated flooring, hard woods, abrasive pines, cement board), ceramics, fibre glass, carbon fibre components, plastics, rubber and soft to medium hard rock formations) |
| |
| PCD is used in Three major areas are: |
| 1. |
Cutting non-ferrous metals and alloys (particularly Si Al in the automotive industry), |
| 2. |
Cutting wood particle board (particularly medium density fibreboard - MDF, and chipboard in the furniture industry), |
| 3. |
Non-cutting applications such as wear-parts |
| |
| GRADES AVAILABLE IN PCD |
| XCF |
<1 micron Easy grinding Precision machining of AL-Si alloy (<12%S) |
| CUF |
2 Micron, Precision machining of Al-Si alloy and wood |
| CF |
4 Micron, Precision machining of Al-Si alloy(>12% Si) |
| CM |
10 Micron, General Purpose |
| CC |
25 Micron, Good wear and chipping resistance |
| CXL |
>25 Micron, Bimodal structure Extreme wear & chipping resistance |
|
| |
| About PCBN |
PCBN in an abbreviation for polycrystalline Cubic Boron Nitride which is a composite formed by sintering together carefully selected cBN particles at very high temperature and pressure in the presence of metal / ceramic catalyst binder material. The end product is a solid, homogeneous layer of PCBN that displays a unique combination of hardness, toughness and thermo-chemical stability, properties wich are increasingly important in a cutting tool material to meet the demands of machining hard ferrous materials. This composite cBN layer can be syntehsised either as free-standing solid material or with a tungsten carbide backing |
|
|
| |
| GRADES AVAILABLE IN PCBN |
| SB100 |
Solid Type, Rough machining of cast iron |
| SB95 |
Very high content cBN, Rough and finish machining of cast iron |
| SB90 |
High thermal stability, machining of cast iron and powder metal alloy |
| SB80 |
Machining of super alloy |
| SB80D |
Very high thermal stability, Machining of ductile cast iron and hard cast iron |
| SB70 |
Rough and light interrupted machining of hardened steel |
| SB60 |
Continuous and light interrupted machining of hardened steel |
| SB50 |
High speed continuous machining of hardened steel |
|
|
|
| |
| |
| |
 |
| |
